Specifications
|
|
SOUND GENERATOR
|
| Piano Sound |
Pure Acoustic Piano Modeling |
| Max. Polyphony |
Piano:Limitless (Solo playing using No.1 to No.8 tones in piano category)
Other: 256 |
| Tones |
Piano: 20 tones
E.Piano: 18 tones
Organ: 18 tones
Strings/Pad: 27 tones
Synth/Other: 279 tones (including 8 drum sets, 1 SFX set) |
|
AMBIENCE
|
| Pure Acoustic Ambience |
Type: Studio, Lounge, Concert Hall, Wooden Hall, Stone Hall, Cathedral
Depth: 11 types |
|
MY STAGE
|
12 types |
Keyboard
|
PHA-50 Keyboard: Wood and Plastic Hybrid Structure, with Escapement and Ebony/Ivory Feel (88 keys) |
Speaker System
|
| Speakers |
Speakers: 8 x 12 cm (3-3/16 x 4-3/4 inches) x 2 (with speaker box)
Dome Tweeters: 2.5 cm (1 inches) x 2 |
| Rated Power Output |
25 W x 2
5 W x 2 |
|
Headphones
|
Headphones Acoustic Projection |
Bluetooth
|
| Audio |
Bluetooth Ver 3.0 (Supports SCMS-T content protection) |
| MIDI |
Bluetooth Ver 4.0 |
|
Compatible Android / iOS Apps (Roland)
|
Roland Piano App
Piano Designer
*Support for the app may be terminated without prior notice. |
Data Playback
|
| Standard MIDI Files |
Standard MIDI Files (Format 0, 1) |
| Audio File (requires a USB flash drive, only supports USB flash drives of 32 GB and under) |
WAV: 44.1 kHz, 16-bit linear format
MP3: 44.1 kHz, 64 kbps–320 kbps |
|
Recorder
|
| Standard MIDI Files |
Standard MIDI Files (Format 0)
Songs: 100
Part: 1
Recording capacity per song: approx. 500 KB |
| Audio File (requires a USB flash drive, only supports USB flash drives of 32 GB and under) |
WAV: 44.1 kHz, 16-bit linear format
Songs: 200
Recording time per song: 80 minutes (approx. 800 MB) |
|
Internal Songs
|
34 Songs |
Tuning, Voicing
|
| Touch Sensitivity |
Key Touch: 100 types, fixed touch
Hammer Response: Off, 10 types |
| Master Tuning |
415.3–466.2 Hz (adjustable in increments of 0.1 Hz) |
| Temperament |
10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key |
| Effects |
Ambience
Equalizer (3-band digital equalizer)
Only for organ tones:
Rotary Speaker Effect
Only for E.Piano tones:
Modulation Speed |
| Mic Effects |
Compressor
Doubling
Echo |
Piano Designer
(Settings can be changed on the piano or through the app.) |
Lid
Key Off Noise
Hammer Noise
Duplex Scale
Full Scale String Resonance
Key Off Resonance
Cabinet Resonance
Soundboard Type
Damper Noise
Soft Pedal Type
Single Note Tuning
Single Note Volume
Single Note Character |
|
Convenient Functions
|
Metronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone)
Tempo Coach
Auto Tempo
Transpose (Keyboard/Song: in semitones)
Registration (45 registrations, capable of pedal shift)
Registration Set
Dual
Split (split point adjustable)
Twin Piano
Tone Demo
Auto Off |
Other
|
| Display |
Graphic LCD 132 x 32 dots |
| Control |
Volume slider
Equalizer sliders (Low/Mid/High)
Part sliders (Lower/Upper)
Song Vol. slider
Mic Vol. slider
Speaker switch
Mic Gain knob |
| Connectors |
DC In jack
Pedal (Damper/R, Sostenuto/C *1, Soft/L *1) jacks: TRS 1/4-inch phone type
Input Stereo jack: Stereo miniature phone type
Output (L/Mono, R) jacks: 1/4-inch phone type
Mic Input jack: 1/4-inch phone type
USB Computer port: USB B type (supports USB MIDI/AUDIO)
USB Memory port: USB A type
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type
MIDI (Out, In) connectors
*1: Assignable |
| Power Supply |
AC adaptor |
| Power Consumption |
40W (When using the included AC adaptor)
*Approximate power consumption when playing the piano at medium volume: 14W
Power consumption when sound has not been played after power-on: 12W |
| Accessories |
Owner’s Manual
Leaflet “USING THE UNIT SAFELY”
AC adaptor
Power cord
Music rest
Damper pedal (DP-10, capable of continuous detection) |
| Option (sold separately) |
Dedicated stand: KSC-90
Dedicated pedal board: KPD-90
Keyboard stand: KS-G8B, KS-11Z, KS-13, KS-20X
Pedal unit: RPU-3
Damper pedal: DP series
Pedal switch: DP-2 (*2)
Expression pedal: EV-5
Carrying Bag: CB-B88V2, SC-G76W3
Headphones
*2 Cannot use for Damper/R. |
|
Size & Weight
|
| Dimensions |
Detached music rest:
1,340 (W) x 390 (D) x 136 (H) mm
52-13/16 (W) x 15-3/8 (D) x 5-3/8 (H) inches
FP-90X with KSC-90 and music rest:
1,340 (W) x 418 (D) x 932 (H) mm
52-13/16 (W) x 16-1/2 (D) x 36-3/4 (H) inches |
| Weight |
23.6 kg, 52 lbs 1 oz (FP-90X with music rest)
37.8 kg, 83 lbs 6 oz (FP-90X with KSC-90, KPD-90, and music rest) |
|
