NUX B-7 Pro Stereo Wireless in-Ear Monitor System, 24-bit 48 kHz Stereo Audio, 2.4 GHz
€370.00
In stock
Description
NUX B-7 Pro Stereo Wireless in-Ear Monitor System, 24-bit 48 kHz Stereo Audio, 2.4 GHz
The NUX B-7 PRO is a personal wireless in-ear monitor system with automatic setup, 2.4 GHz interference-free broadcasting frequency, and 24-bit 48 kHz high-quality stereo audio. The operation range is up to 50 meters (160-feet) with very low latency wireless transmitting.
| Specifications | |
| Operating Frequency Band | 2400-2483.5MHz |
| Transmit Mode | Frequency Hopping |
| RF Output Power | 10mW E.l.R.P. max |
| Audio Quality | 24bit/48kHz |
| Frequency Response | 20Hz-20kHz |
| Latency | 7.33ms(low latency setting)-10.85ms(default)-14.33ms(safe setting) |
| Unbalanced Input lmpedance | 10kΩ |
| Balanced Input lmpedance | 20kΩ |
| AUX Input Level | 2.1 Vrms(8.7dBu) max |
| Balanced Input Level | 9.8 Vrms(22dBu)max |
| Headphone output Impedance | Minimum 13Ω |
| Headphone Maximum output power per channel | 57mW (THD<0.1% RLOAD=16Ω,1kHz) |
| Channel separation | -105dB |
| THD+N | <0.01% typical |
| Dynamic Range | 110dB A-weighted |
| Output level Adjustment Range | Mute -86dB~+12dB |
| Auto-0ff | It automatically turns off after 10 minutes of no connection or if the connection is lost |
| Built-in Battery Capacity | Rechargeable Li-polymer (Transmitter 3.7V/3000mAh, receiver 3.7V/400mAh) |
| Battery Lifetime | TX: Up to 6 hours/ RX: Up to 6 hours |
| Power Requirements | DC 9V, 1A min, negative tip power supplies(Transmitter) |
| Operation Range | Up to 50m (165 feet) maximum |
| TX Dimesions | 140mm*97mm*53mm (L*W*H) |
| TX Weight | 525g |
| RX Dimensions | 47mm*71mm*22mm (L*W*H) |
| RX Weight | 51g |
Additional information
| Weight | 0.35 kg |
|---|---|
| Brand |
